COM-Express Module |
Standard |
COM Express basic type 2 |
|
Model number |
TBD |
|
CPU |
Core 2 Duo / Pentium M |
|
Current consumption |
Up to 4.5 A (12 V) |
|
VME |
Tsi 148 PCI-VME Bridge |
Tsi 148 PCI-VME Bridge |
|
SATA |
2 ch (Built-in COM Express) |
2 ch (Built-in COM Express) |
|
Ethernet |
10/100 / 1000base |
1 ch (Built-in COM Express) |
|
USB |
USB 1.1 / 2.0 |
4 ch (Built-in COM Express) |
|
Expansion |
PMC |
PCI 64 bit / 66 MHz |
|
XMC |
PCIe x 4 |
|
Outline |
233.35 (L) x 160 (W) (mm) |
|
|
Input Power |
5, 12 V ± 5% (receiving from backplane) |
|
|
Usage environment |
0 to 40 ° C |
|
|
90% RH or less (non condensing) |
|
